ADAS calibration for cars
Autocom ACS CARS Calibration is a mobile product, designed specifically for the calibration of the assistance systems on passenger cars and light commercial vehicles.
Mobile and flexible
The mobile calibration device (rig) with reference targets works on most brands and models and are developed in accordance with manufacturer specifications. The equipment is easy to transport and has short set-up-time. That makes it ready for use on the spot in practically no time.
The rig is also wider than others, which makes it possible to use even for transport vehicles like LCV (light commercial vehicles).
Your advantages
- Secure solution
- Fast set-up
- Time saver
- Easy handling
- One-person operation
- Maximum flexibility
- Wide brand coverage
- Generate additional sales
Targets
Our calibration targets are double side printed and can be used for different vehicles. So if you buy one target, you can use it on two different brands.
*Calibration target can only be used in combination with target adjustment rails.
TFC 1 / TFC 2
Front: Audi, Cupra, Seat, Škoda, Volkswagen
Rear: Volvo, Mercedes, Polestar
TFC 3 / TFC 4
Front: Renault
Rear: Citroën, DS Automobiles, Opel, Vauxhall, Peugeot
TFC 5 / TFC 6
Front: Fiat, Hyundai, Jeep, KIA
Rear: Alfa Romeo
TFC 7 / TFC 8
Front: Nissan, Mercedes
Rear: Mazda
TFC 9 / TFC 10*
Front: Mazda
Rear: Mitsubishi
TFC 11 / TFC 12*
Front: Suzuki, Toyota, Lexus, Mazda
Rear: Toyota
TFC 13 / TFC 22
Front: Nissan
Rear: Toyota
TFC-15 / TFC-16 / TFC-17*
Front: Honda
Rear: Hyundai, KIA
TFC 20 / TFC 21
Front: Suzuki Jimny
Rear: Isuzu D-Max II
360° calibration target mats
Manufacturer specific target mats for calibration of 360° surround view camera systems.
Target mat rear view VAG (TRV-1)
For calibration of rear view camera on VAG vehicles.
Target mat rear view MB (TRV-2)
For calibration of rear view camera on MB light commercial vehicles.
Accessories
Complete your ADAS rig with some of our accessories.
Target adjustment rails
Adjustment rail kit for holding the cars and LCV calibration targets. The kit includes one rail for the top and one rail for the bottom.
Radar reflector (TFR-2)
Reflector plate for static adjustments of the radar systems on some cars and LCV. It includes reflector plate, holding device and distance laser.
Radar kit calibration aid Volvo
Adjustment tool for various Volvo radar sensors. This tool allows for the correct adjustment of the radar sensor after installation.
Camera kit calibration aid Volvo in the bracket after installation.
Adjustment tool for various Volvo front camera systems. This tool ensures correct levelling of the camera unit
Additional mobility unit
Extra pair of wheels that can be mounted on the rig to increase the turning radius to 360° on the spot.
Stretcher arms
Extension arms for wheel clamps to prevent scratches to rims caused by metal pins
Handle
Extra handle to mount on the rig.
Good to have when using additional mobility unit
CARS software
ACS CARS must be used in combination with Autocom CARS diagnostic software.
Useful help texts with instructions (such as panel height, distance from the vehicle, alignment, etc.) for the correct positioning of the rig. Easy step-by-step guides throughout the procedures are provided for each make and/or model in the software.
After calibration a report can be printed to hand over to the customer with the evidence of the operations carried out.
How it works
During a test of advanced driver assistance system, camera calibration for example, use the calibration targets as reference spot after given measurements from the OE. Activate the camera calibration through diagnostics commands in the Autocom CARS software.
The camera reads the target pattern for the specific vehicle. And then processed by the camera unit to confirm that the values are correct. If the camera unit finds values outside the tolerance, the system will notice this and give a DTC (fault code) in the software. A warning light will also be displayed in the vehicle.
